RIG22 1000W High Power Resistor For Microwave Systems

RIG22 1000W High Power Resistor For Microwave Systems

Description

The RIG22 series from BOCHEN is a high-performance power resistor designed for applications that demand precision, durability, and heat endurance. Built on a ceramic core with a flame-retardant coating, RIG22 ensures exceptional thermal conductivity, electrical stability, and mechanical strength under continuous high-power loads.

With a power rating up to 1000W and resistance range from 1Ω to 500Ω, the RIG22 performs reliably in high-load, high-temperature environments. Offering tight tolerances (±1%, ±5%, ±10%) and a TCR of ±300ppm/°C, it is ideal for power circuits where accuracy and reliability are critical.

Fully RoHS and REACH compliant, and engineered for SMD/SMT mounting, RIG22 provides seamless integration into industrial systems, automotive platforms, and medical-grade devices.

Features

• Power Rating: Up to 1000W

• Resistance Range: 1Ω to 500Ω

• Tolerance Options: ±1%, ±5%, ±10%

• Temperature Coefficient: ±300ppm/°C

• Operating Temperature: -55°C to +165°C

• Construction: Flameproof, ceramic core design

• Compliance: RoHS & REACH certified

• Mounting: SMD/SMT

Specifications

Applications

RIG22 is built for precision and resilience across demanding applications:

• Power Supplies: Load and surge resistors in switching and linear PSUs

• Motor Drives & Controllers: Snubber circuits, current sensing, braking systems

• Inverters & Converters: High-voltage, high-frequency energy regulation

• Medical Equipment: Stable resistive elements in diagnostic and imaging devices

• Test & Measurement: High-accuracy resistance in lab and field instruments

• Automotive Electronics: Signal conditioning and power regulation in BMS and ECUs

• Lighting Systems: Energy dissipation and voltage control in ballast circuits

• Industrial Automation: Reliable components in PLCs, sensors, and control gear

Why Choose BOCHEN RIG22?

• Direct from Manufacturer — No middlemen, competitive pricing

• Certifications Ready — RoHS, REACH, and ISO quality assurance

• Fast Production — Scalable capacity and quick turnaround

• Expert Support — Dedicated after-sales and technical assistance

• OEM/ODM Services — Custom specifications available on request

Consistent Performance. Industrial Reliability.

Whether you’re developing power control systems, precision instruments, or high-reliability electronics, the RIG22 power resistor delivers the performance you need — with the durability you can trust.
