Fully Sealed Single Turn Cermet 100k Trimmer 3387P-1 Top Adjustment

Products

Conductive Plastic Potentiometer

Fully Sealed Single Turn Cermet 100k Trimmer 3387P-1 Top Adjustment

MOQ:	100 Pieces
Price:	$0.98 - $1.80/Piece
Standard Packaging:	Standard Packing 50 Pieces/Tube
Delivery Period:	1-7 Workdays
Payment Method:	T/T, L/C, D/A, D/P, Western Union
Supply Capacity:	10000000 Pieces Per Month

Detail Information

Product Description

Detail Information

Place of Origin

Chengdu

Brand Name

BOCHEN

Certification

RoHS, Reach

Model Number

3387P-1

Product Name:

3387P-1 0.5w Top Adjustment Single Turn Cermet Trimmer Potentiometer

Resistive Material:

Cermet

Adjustment Method:

Top Adjustment,extended Square Shaft

Mounting Style:

Through Hole

Resistance Range:

10Ω-5MΩ

Resistance Tolerance:

±10% ；±20%

Electrical Travel:

Total Mechanical Travel:

Contact Resistance Variation (CRV):

≤3%R Or 3Ω

Rated Power(300 Volts Max.):

70℃，0.5W；125℃，0W

Minimum Order Quantity:

100 Pieces

Price:

$0.98 - $1.80/Piece

Packaging Details:

Standard Packing 50 Pieces/Tube

Delivery Time:

1-7 Workdays

Payment Terms:

T/T, L/C, D/A, D/P, Western Union

Supply Ability:

10000000 Pieces Per Month

Highlight:

Fully Sealed 100k trimmer

3387P-1 100k trimmer

3387 trimmer Top Adjustment

Product Description

3387P 0.5w Top Adjustment Single Turn Cermet Trimmer Potentiometer With Extended Square Shaft

Feature

• Small size, fully sealed.

• Cermet resistive element.

• Extended square adjustment shaft.

• Through hole mounting.

• Power rating 0.5W at 70℃.

• Resistance range 10Ω to 5MΩ, resistance tolerance 10%.

• Electrical travel 220°, total mechanical travel 250°.

Description

The 3387P cermet trimmer is a compact, fully sealed component designed for precise resistance adjustment in a variety of electronic applications. This trimmer features a cermet resistive element, ensuring durability and stability under various environmental conditions. An extended square adjustment shaft allows for easy and accurate tuning, even in tight spaces. It is designed for through-hole mounting, making it compatible with a wide range of circuit boards.

With a power rating of 0.5W at 70℃, the 3387P is capable of handling moderate power levels while maintaining performance integrity. Its resistance range spans from 10Ω to 5MΩ, with a resistance tolerance of 10%, offering flexibility for different circuit requirements. The trimmer also boasts an electrical travel of 220° and a total mechanical travel of 250°, providing a broad adjustment range for fine-tuning applications. Overall, the 3387P-1 cermet trimmer is a reliable choice for achieving precise resistance control in compact electronic designs.

Specification

Electrical Characteristics	Nominal Resistance Range	10Ω~5MΩ
	Resistance Tolerance	±10%; ±20%
	Terminal Resistance	≤±1% R or 3Ω
	Contact Resistance Variation (CRV)	≤3%R or 3Ω
	Insulation Resistance	500 Vdc. 100 megohms min.
	Withstand Voltage	101.3KPa, 500 Vac; 8.5KPa, 250 Vac
	Dielectric Strength Sea Level	500 Vac(1min.)
	Effective Travel	220°
Environment Characteristics	Weld Heat Resistance	250℃, 10 Sec.
	Rated Power	70℃, 0.5W; 125℃, 0W
	Temperature Range	-55°C ~ + 125°C
	Temperature Coefficient	±250, ±100 ppm /°C
	Temperature Variation	ΔR≤±3%R, Δ(Uab/Uac)≤±1%
	Collision	20G, ΔR≤±1%R, Δ(Uab/Uac)≤±1%
	Vibration	100G, ΔR≤±1%R, Δ(Uab/Uac)≤±2%
	Electrical Endurance At 70°C	1000 hours @ 70℃ Rated Power; ΔR≤±3%R
	Mechanical Endurance	200 cycles, ΔR≤±3%R
Physical Characteristics	Total Mechanical Travel	250°
	Starting Torque	≤25 mN.m
	Clutch Torque	≤35 mN.m

Dimension

Fully Sealed Single Turn Cermet 100k Trimmer 3387P-1 Top Adjustment 0

Packaging

Packaging specification: 50 pieces per tube.

Fully Sealed Single Turn Cermet 100k Trimmer 3387P-1 Top Adjustment 1

Application

• Calibration of Electronic Devices

• Industrial Control

• Medical Devices

• Communication Equipment

• Consumer Electronics

• Aerospace

• Automotive Electronics

Advantage

• Factory direct supply, no middlemen.
• Completed certificates such as Rohs Reach, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM & ODM available.
