Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor

MOQ: 100 Pieces
Price: $0.13 - $0.16/piece
Standard Packaging: Bulk (1000 units per box); Magazine / Automatic Insertion (80 units per magazine).
Delivery Period: 1-7 Workdays
Payment Method: T/T,L/C,D/A,D/P,Western Union
Supply Capacity: 3,000,000 Pieces Per Month
Detail Information
Product Description
Detail Information
Place of Origin
Chengdu
Brand Name
BOCHEN
Certification
RoHS, Reach
Model Number
PT6
Product Name:
PT6 0.1w 220 Ohms To 5 Megohms 20% 6mm Carbon Through Hole Trimmer Resistor Potentiometer
Product Type:
Single Turn Trimmer Resistors
Element Type:
Carbon
Termination Style:
Through Hole
Adjustment Style:
Top Crossed Slot
Mounting Style:
PCB Mount
Nominal Resistance Range:
220 Ohms To 5 Megohms
Tolerance:
20%
Power Rating:
0.1W
Diameter:
6 Mm
Highlight:

Pt6kv Carbon Film Trimmer Resistor

,

Top Adjustment Carbon Film Trimmer Resistor

,

Piher Carbon Film Trimmer Resistor

Product Description

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor



Description

The PT6 Series from BOCHEN is a 6mm carbon trimmer potentiometer designed for reliable and precise resistance adjustments across a wide range of low-power electronic applications. Engineered with a carbon resistive element and available in various taper profiles—including linear, logarithmic, and antilogarithmic—the PT6 delivers consistent performance, smooth rotational adjustment, and long operational life.



Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 0



Whether you're working on appliance controls, timer circuits, or consumer electronics, the PT6 offers the flexibility, reliability, and ease of integration that modern designs demand.

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 1

Features

  • Compact 6mm footprint for space-constrained applications

  • Carbon resistive element for stable and precise resistance control

  • Wide resistance range: 220Ω to 5MΩ

  • Taper options: Linear, logarithmic, antilogarithmic

  • Up to 10 mechanical detents for tactile feedback

  • Rated life up to 10,000 cycles

  • SPDT switch option available

  • Wiper position: Initial, 50%, or fully clockwise

  • IP54 protection against dust and splashes

  • Packaged in magazines for automatic insertion

  • Optional shafts and knobs for fast assembly

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 2

Specification



Electrical Specifications Taper Lin
Standard Resistance Range 220Ω ≤ Rn ≤ 5MΩ
Standard Resistance Tolerance ± 20%
Max. Voltage 100 VDC
Nominal power 50°C (122°F) 0.1 W
Residual resistance ≤ 0.5% Rn (5Ω min.)
Equivalent noise resistance ≤ 3% Rn (3Ω min.)
Operating temperature -25°C to +70°C
Mechanical Specifications Mechanical rotation angle 235° ± 5°
Electrical rotation angle 200° ± 20°
Rotational Torque 0.2 to 2 Ncm (0.3 to 2.7 in-oz)
Stop Torque > 4 Ncm (>7 in-oz)
Life up to 10.000 cycles
Environmental Testing Electrical life 1.000h at 50°C; 0.1 W; ±5%
Mechanical life 1000 cycles at 10 to15 cpm;
±3% (Rn < 1M )
Temperature coefficient –25° C; +70° C;
±300 ppm/°C C (Rn < 100K)
Thermal cycling 16h at 85°C and 2h at -25°C; ±2.5%
Damp heat 500h at 40°C and 95% relative humidity (RH); ±5%
Vibration 2h each plane at 10Hz - 55Hz; ±2%
Storage 6 month at 23°C ±2°C and 50% RH; ±2.5%




Dimension



Dimensions in mm, tolerances ±0.30 mm unless otherwise specified.

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 3

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 4



Applications

  • Appliance Program Selectors

  • Thermostat Controls

  • Timers & Relays

  • Consumer Electronics

  • Power Tool Interfaces

  • Test & Measurement Devices



Why Choose BOCHEN PT6?

  • ✅ Factory-direct pricing with no middlemen

  • ✅ Certified quality: RoHS, REACH, and ISO compliance

  • ✅ Fast delivery and scalable production

  • ✅ Dedicated technical & after-sales support

  • ✅ Custom OEM & ODM options available

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 5



Dependable Precision in Every Turn.
The BOCHEN PT6 potentiometer is your go-to solution for compact, precise, and cost-effective resistance control in modern electronics.



Advantage



• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, REACH, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM & ODM available.



Product Catalog



Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 6

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 7

Piher Pt6kv Potentiometer Top Adjustment Carbon Film Trimmer Resistor 8
